Interruptor Automático Fijo 4 polos 1250A MicroLogic 2.0 Schneider Electric C125N420FM NS1250N

Interruptor Automático Fijo 4 polos 1250A MicroLogic 2.0 Schneider Electric C125N420FM NS1250N

Condición: NUEVO SELLADO.

Este interruptor automático de la serie ComPacT NS new generation es un dispositivo de 4 polos con una corriente nominal de 1250 A a 50 °C. Cuenta con una unidad de control electrónica MicroLogic 2.0 y ofrece una capacidad de ruptura de 50 kA a 415 V AC. Su montaje es fijo y su operación es manual, ideal para aplicaciones de distribución. La protección incluye funciones de sobrecarga (L) y cortocircuito instantáneo (I), con ajustes de captación y retardo de tiempo prolongado.

Especificaciones

• Range: ComPacT
• Product name: ComPacT NS new generation
• Range of product: ComPacT NS630b...1600 new generation
• Product or component type: Circuit breaker
• Device application: Distribution
• Poles description: 4P
• Protected poles description: 4D
• Neutral position: Left
• [In] rated current: 1250 A at 50 °C
• [Ue] rated operational voltage: 690 V AC 50/60 Hz
• Network type: AC
• Network frequency: 50/60 Hz
• Suitability for isolation: Yes conforming to EN/IEC 60947-2
• Utilisation category: Category B
• Breaking capacity code: N 50 kA 415 V AC
• Trip unit name: MicroLogic 2.0
• Trip unit technology: Electronic
• Trip unit protection functions: LI
• Control type: Manually operated
• Mounting mode: Fixed
• [Ui] rated insulation voltage: 800 V AC 50/60 Hz conforming to IEC 60947-2
• [Uimp] rated impulse withstand voltage: 8 kV conforming to IEC 60947-2
• [Icw] rated short-time withstand current: 19.2 kA 1 s conforming to IEC 60947-2
• Mechanical durability: 10000 cycles
• Electrical durability: 2000 cycles at 690 V In3000 cycles at 690 V In/24000 cycles at 440 V In5000 cycles at 440 V In/2
• Power losses: 44 W
• Mounting support: Backplate
• Upside connection: Front
• Downside connection: Front
• Connection pitch: 70 mm
• Protection type: L
• Trip unit rating: 1250 A at 50 °C
• Long time pick-up adjustment type Ir: Adjustable 9 settings
• Long time pick-up adjustment range: 0.4...1 x In
• Long time delay adjustment type: Adjustable 9 settings
• [tr] long-time delay adjustment range: 12.5...600 s at 1.5 x Ir0.5...24 s at 6 x Ir0.7...16.6 s at 7.2 x Ir
• Thermal memory: 20 mn
• Instantaneous pick-up adjustment type Ii: Adjustable
• Instantaneous pick-up adjustment range: 1.5...10 x Ir
• Earth-leakage protection: Without

Peso informado por el distribuidor: Net weight: 18 kg
