Bobina Solenoide BE240AS 240V 50Hz Danfoss 018F6177

Bobina Solenoide BE240AS 240V 50Hz Danfoss 018F6177

Condición: NUEVO SELLADO.

Esta bobina solenoide BE240AS de Danfoss opera con un voltaje de alimentación de 240V AC y una frecuencia de 50 Hz. Su diseño de conexión es DIN Spade y cuenta con una clasificación de protección IP20. La bobina tiene un rango de temperatura ambiente de -40 °C a 80 °C. Es compatible con diversos programas de piezas como EV210B y EV220B.

Especificaciones

• Gross weight: 0.294 Kilogram
• Net weight: 0.277 Kilogram
• Volume: 0.275 Liter
• EAN: 5702428024426
• Type: BE240AS
• Product group: Solenoid valves
• Product Name Description: Solenoid coil
• Actuator size: 13.5 mm
• Ambient temperature range [°C] [max]: 80 °C
• Ambient temperature range [°C] [min]: -40 °C
• Ambient temperature range [°F] [max]: 175 °F
• Ambient temperature range [°F] [min]: -40 °F
• Approval: CE EAC LLC CDC TYSK
• CE evaluated: Yes
• China RoHS compliance: Out of scope
• China RoHS exemption clause: No
• Coil connection: DIN Spade
• Coil design standard: VDE 0580
• Coil fastening: Clip-on
• Coil winding insulation class: Class H to IEC 85
• Colour: Blue
• Compliance: EN 60730-1
• Contains batteries: No
• Duty rating: Continuous
• EEE category: 5 small equipment (any external dimension < 50 cm)
• Electrical connection: DIN Spade
• Electrical connection size: 6.3 mm x 0.8 mm
• Electrical connection standard: EN175301-803
• Electrical connector: 3 x spades
• Enclosure rating IP: IP20
• EU RoHS compliance: Yes
• EU RoHS exemption clause: No
• Frequency [Hz]: 50 Hz
• In scope of WEEE: Yes
• Packing format: Multi pack
• Parts included: Cap
• Parts Program name: EV210B EV212B EV220B 15 - 50 EV220B 6 - 22 EV220B 65 - 100 EV222B EV224B EV227B EV250B EV251B
• Power consumption 50Hz [VA]: 19 VA
• Power consumption [W] 50Hz: 11 W
• Product accessories: Solenoid coil accessories

Peso informado por el distribuidor: Net weight 0.277 Kilogram
